Customized Mbr Membrane Wastewater System

Basic Info

Material	Pes, Pan, PVDF
Technical Support	Fully Support
Membrane Type	Reinforced PVDF Hollow Fiber Membrane
Customized	Approve
Application1	Municipal Wastewater
Application2	Reclaimed Water Recycling
Application3	Livestock Farm Wastewater Treatment
Application4	Wastewater Reuse in Commercial Buildings
Construction Work	Civil Works or Containerized Type
Feature	High Efficiency
Marketing Type	Immersed Mbr Membrane
Product Characteristic	Submerged Membrane Bioreactor
Power	by Customer′s Requirement
Transport Package	Well Export Wooden or Carton Case
Specification	Customized
Trademark	Jhui or custmoized
Origin	China Mainland
HS Code	8421999000
Production Capacity	50000000 PCS Per Year

Product Description

High quality mbr membrane wastewater treatment plant system for Textile wastewater treatment
1. MBR membrane bioreactor system technology introduction
1.1. Membrane bio-reactor ( membrane Bio-Reactor, MBR) is a Membrane unit is introduced into traditional sewage biological treatment technologyof the new processing technology, Membrane separation unit in replace of traditional secondary sedimentation pool function at the same time, withfurther removal of organic matter and nitrogen and phosphorus, is currently the most advanced and efficient water treatment technology.

MBR system for removal of organic matter from the water (NH3-H), ammonia nitrogen, total nitrogen and total phosphorus (TN). The user can accordingto the requirements of combined anaerobic, anoxic, aerobic process, to achieve water requirements.

Our MBR System includes Hollow Fiber UF Membrane MBR system and Flat Sheet Membrane MBR system. Hollow Fiber UF Membrane MBR system is a waste water treatment system with MBR Bio-reactor as the core device, including raw water tank/ aeration device/ dosing device and backwashingdevice, etc.

1.2.Hollow fiber uf membrane MBR System process flow:
1.3.Jinhuimo MBR membrane operation parameters:

Model	JHM-MBR-1 BXLXW		JHM-MBR-2 BXLXW
Specification	630x1500x36		630x2000x36
ID/OD(mm)	1.5/2.6	1.0/2.2	1.5/2.6	1.0/2.2
Effective membrane area(m2)	15		20
Filtration precision(um)	0.1	0.034	0.1	0.034
Membrane shell material	ABS
Membrane material	PVDF&PET supporting tube
Connecting pipe specification	Φ32
Catchment way	Both end of the catchments
Filter type	Immersion suction filtration
PH	2-12
Temperature(ºC)	10-45
Oil content(mg/l)	<3
TMP(Mpa)	0.02-0.05
Reverse flushing pressure(Mpa)	0.1
Aeration rate	Gas water rato 15:1-20:1
Allow sludge concentration(mg/l)	4000-12000
Design flux(l/m2·h)	10-40

1.4. Advantages of Jinhuimo MBR membrane bio-reactor:
1)JHM MBR membrane is high efficiency, especially capable in frequent disuse occasions;
2)A longer shelf life than other manufacturers;
3)Anti-oxidant modification on the in-let membrane surface makes it more durable in harsh environment like wastewater;
4)Fine inner diameter of the membrane fiber can ensure that sludge blocks the membrane pore the instant the fiber is broken accidentally, endowing the membrane with self-repairing function without affecting outflow water quality.



1.5. MBR membrane system design
We have a professional technician department who will study and design the MBR membrane and system by your requirements, pls helpto provide your detailed info. as more as better for us.

2. Company introduction:
Shandong Jinhuimo Technology is a high-tech enterprise specializing in the research and development/production/application/membrane technology and engineering design of hollow fiber membrane separation technology in China. we have a professional team ofnearly 20 years engaged in research and development of membrane technology and water treatment engineering application experience,advanced ultrafiltration membrane module production capacity and large enterprise base. It has passed ISO 9001:2000 quality managementsystem and SGS certification.Country stock code :831623.

3. MBR curtain type hollow fiber membrane bio reactor system application:
*Food industry: process water/ production water preparation/ sewage treatment.*Beverage industry: process water/ production water/ concentrated separation treatment.*Pharmaceutical industry: process water/ preparation water/ washing water/ injection water/ aseptic water preparation.*Chemical industry: production water/ wastewater treatment/ water reuse.*Power industry: boiler recharge water/ circulating cooling water.*Electronics industry: semiconductor industry ultrapure water/ integrated circuit cleaning water/ formula water.*Petrochemicals: oil field injection water/ petrochemical wastewater deep treatment/ chemical wastewater treatment and reuse.*Desalination of sea water and brackish water: island areas/ coastal areas/ ships/ seawater oil fields/ etc. production/ domestic water.*Drinking water engineering: pure water preparation/ drinking water purification/ water standard-raising.

4. Jinhuimo list only three cooperation cases show for you:5.Jinhuimo mainly provide waste waste water treatment products:
5.1. UF ultrafiltration membrane;5.2. UF ultrafiltration membrane system;5.3. MBR hollow fiber membrane;5.4. MBR hollow fiber membrane system;5.5. Integrated equipment system(AO,AAO,MBBR.etc.);5.6. Reverse osmosis(RO) membrane;5.7. Reverse osmosis(RO) membrane system;5.8. Moving bed biofilm reactor(MBBR);5.9. Disic and tube air diffusers, etc.

6. We Jinhuimo company attended to international exhibitions listed in these 2 years:
In 2018, we attended to Russia, Malasia, Vietnam Water exhibition;In 2019, we attended to Thailand, Pakistan, Indonesia, India water exhibition;

All we did is finding each other, if you need our MBR hollow fiber membrane or system, warlmly welcome to contact with us!
